UPS Riello Sentryum

Category: Product ID: 2515

Description

Power Range: 10 – 120 kVA

3:3 1-3:1

Our third generation of transformerless ON LINE UPS systems, the 10-120 kVA Sentryum rewrites the concept of flexible power by offering a choice of three compact cabinet sizes to suit the needs of any small data centre or mission-critical application.

Enhanced overload and short circuit capacity guarantee maximum availability. Incorporating a 5-inch colour touchscreen display and intuitive LED status indicator that automatically changes colour based on the UPS’s current operating state.



Models S3M 10 CPT
INPUT
Rated power 10000 VA
Voltage 380 / 400 / 415 V three-phase + N – 220 / 230 / 240 V single-phase + N
Voltage tolerance 230 / 400 V ±20% @ full load (for wider tolerance conditions apply)
Frequency tolerance 40 – 72 Hz
Power factor 0.99
BY PASS
Rated voltage 220 / 230 / 240 V single-phase + N
Voltage tolerance From 180 V (adjustable 180-200) to 264 V (adjustable 250-264) referring to neutral (Ph-N)
Rated frequency 50 or 60 Hz (selectable)
Frequency tolerance ±5% (selectable)
Number phases 1 + N
OUTPUT and INVERTER OUTPUT
Rated power 10000 VA
Active power 10000 W
Output current 48 (bypass) A – 43 (inverter) A
Number phases 1 + N
Crest factor (Ipeak/Irms) 3 : 1
Waveform Sinusoidal
Static stability ±0.5%
Dynamic stability EN 62040-3 class performance 1 non-linear load
Frequency 50 or 60 Hz
Voltage distortion with non-linear load ≤1.5%
Voltage distortion with linear load <1%
BATTERIES
Type VRLA AGM/GEL/NiCd/Li-ion/Supercaps
Type of charging One level, Two level, Cyclic recharge (selectable)
ENVIRONMENTAL
Color RAL 7016
Communication UPS status led bar – Graphic touch screen display – 2 slots for communications interface USB – RS232 – Contact interface with 5x opto insulated Input and 4x Output relays
Protection rating IP20
Line-Interactive/Smart Active efficiency Up to 99%
Noise (at 1 m) <40 [dBA ±2] (SMART ACTIVE)
Remote signals voltage free contacts
Operating temperature 0 °C – +40 °C
Relative humidity 5-95% non-condensing
Standards European directives: LV 2014/35/EU low voltage; EMC 2014/30/EU electromagnetic compatibility — Directive and Standards: Safety IEC EN 62040-1; EMC IEC EN 62040-2; RoHS compliant — Classification in accordance with IEC EN 62040-3 VFI – SS – 111
DATA
Weight 48 kg
Dimensions (h w d) 700x280x840 mm
